Dimensions
442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
Max. PoE Output
Up to PoE+
Total PoE Availability
195W
Form Factor
Rack mount (1U)
Switching Capacity
104 Gbps
Total Non-Blocking Throughput
52 Gbps
MAC Address Table Size
16,000
Packet Buffer Size
1.5 MB
LACP Port Aggregation
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Multicast & Broadcast Rate Limiting
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Max. PoE Wattage per Port by PSE
Max. Power Consumption
45W (Excluding PoE Output) 240W (Including PoE Output)
Power Method
Universal input, 100—240V AC, 50/60 Hz
Power Input Method
AC input
Power Supply
AC/DC, internal, 240W
Supported Voltage Range
100—240V AC
Heat Dissipation (Excluding PoE Output)
153.54 BTU/hr
Weight
Without mounting brackets: 4.5 kg (10 lb) With mounting brackets: 4.6 kg (10.2 lb)
Enclosure Material
SGCC steel
Supported Rack Depth
400~1200 mm (15.7-47.2")
LCM Display
1.3" touchscreen
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
ESD/EMP Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
